ABB AO810 3BSE008522R1 Analog Output Module

ABB AO810 3BSE008522R1 is an analog output module with 8 unipolar analog output channels. The communication with the D/A - converters is monitored by reading back the serial data, with open circuit diagnostics during the readback. The module can perform self-diagnosis cyclically, including process power supply monitoring, reporting channel errors when the output circuit supply voltage is too low. The channel diagnostics detect faults on the active channels and report errors when the output current is less than the set value (the set value is greater than 1mA).

Fuctions & Features

• Output channel configuration: It has 8 unipolar analog output channels, which can output 0-20mA, 4-20mA and other signals, which can be used to drive control valves, inverters, etc.

• Fault response function: It has OSP (Output State Protection) function, which sets the output to a preset state when an error is detected.

• Avoid short circuit: The analog output is short-circuit protected and can be grounded (ZP) or connected to +24V.

Specification
