The Honeywell MC-PHAI01 51403479-150 is a C300 Analog Input Module that provides a single 4-20 mA or 0-10 V analog input channel. It is designed for use in industrial automation applications where precise measurement of analog signals is required.

Features

• Single 4-20 mA or 0-10 V analog input channel
• Input range: 4-20 mA or 0-10 V
• Input accuracy: ±0.2%
• Input resolution: 16 bits
• Input update rate: 100 Hz
• Redundant input support
• Remote input support
• SNTP time synchronization

Technical Specifications

• Manufacturer: Honeywell
• Part Number: MC-PHAI01
• Supported control network: Only FTE (Currently, each C300 must be connected to a control firewall)
• Device index configuration: Between 1 and 510
• IOTA size: 6 feet
• Supports I/O links for several days: 2
• Available input/output link speed:
  • 375 Kbaud (PM INPUT/output only)
  • 750 Kbaud (C Series input/output only)
• Supported base execution period: 50 milliseconds
• Support redundant: Yes
• Remote input/output is supported: Supports -PM input/output or A series
• Input/output module during execution: 50 milliseconds
• Configurable values during CM/SCM execution: 50, 100, 200, 500, 1000, 2000 milliseconds
• Configurable values for like-for-like update rates (period): 100, 200, 500, 1000 milliseconds
• C300 Time resources: SNTP
• SNTP update period: 1 min
• Shipping Weight: 2 Kg
