ABB TU834 3BSE040364R1 Module Termination Unit

The ABB TU834 3BSE040364R1 is a robust Terminal Unit (TU) from ABB’s AC 800M family, engineered to offer a reliable, structured connection interface between field devices and I/O modules. As part of the S800 I/O series, the TU834 supports high-density signal processing with excellent modularity, ideal for distributed control systems in industrial automation.

Designed for redundant and non-redundant applications, TU834 provides connectivity to one or two I/O modules and incorporates a backplane for the communication and power interface. Its compact and rail-mounted form factor ensures easy integration in confined control cabinet spaces.

Product Advantages

• Flexible I/O Configuration: Compatible with both single and redundant I/O modules.

• High Channel Density: Supports up to 32 channels, enhancing cabinet space utilization.

• Easy Maintenance: Allows module replacement without disturbing wiring, reducing downtime.

• Field-Proven Reliability: Backed by ABB’s rigorous quality and reliability testing.

• Integrated Diagnostics: Supports status indication and troubleshooting features.

• Plug-and-Play Installation: Simplifies wiring and minimizes commissioning time.

• DIN-Rail Mountable: Fast and stable mechanical installation.

Technical Specifications

Applications

The TU834 terminal unit is widely used in multiple industrial sectors requiring high-integrity control and monitoring of I/O signals. Its adaptability and design allow it to operate efficiently in both safety and non-safety systems.

• Oil & Gas Refineries

• Power Generation Plants

• Chemical and Petrochemical Facilities

• Water Treatment and Distribution

• Metals and Mining Industries

• Pharmaceutical Manufacturing

• Food and Beverage Processing

• Pulp and Paper Mills

Its high reliability and support for redundant configurations make it ideal for mission-critical systems where downtime must be minimized.

FAQs

Q1: What is the main function of the ABB TU834 3BSE040364R1?

A1: The TU834 acts as a terminal base for I/O modules in the S800 series, providing physical connections for wiring and a backplane interface for communication and power.

Q2: Can the TU834 be used in redundant systems?

A2: Yes, it fully supports redundant I/O configurations, allowing dual modules to ensure system continuity in case of failure.

Q3: What type of mounting is used for TU834?

A3: It is designed for DIN-rail mounting, which allows for easy installation and removal.

Q4: Is hot swapping supported with the TU834?

A4: Yes, the terminal unit allows for the replacement of I/O modules without disconnecting field wiring or shutting down the system.

Q5: What I/O modules are compatible with TU834?

A5: It supports a wide range of S800 I/O modules including DI801, DO801, AI801, AO801, and others.

Q6: What are the temperature tolerances of the TU834?

A6: It operates from -40°C to +70°C and can be stored between -40°C and +85°C.

Q7: Is there any diagnostic functionality in TU834?

A7: While diagnostics are mainly handled by the I/O modules, the TU834 supports status indication via connected modules and system interfaces.

Q8: What type of field connections does the TU834 offer?

A8: It provides pluggable terminals which can be either screw-type or spring-clamp depending on field wiring preferences.

Q9: Does the TU834 require any special configuration?

A9: No special configuration is needed. It acts as a passive unit and is recognized through the I/O module and system integration.

Q10: Can I mix different I/O modules with a single TU834?

A10: No, each TU834 is designed to host a specific I/O module or a pair in redundancy. Mixed modules require separate terminal units.
