ABB CI871AK01 CI871A 3BSE092693R1 Interface Module

The ABB CI871AK01 (CI871A) 3BSE092693R1 is a high-performance communication interface module designed for integration into ABB’s AC 800M control system, enabling seamless connectivity between the controller and external devices via PROFINET IO. As part of the S800 I/O series, it acts as a gateway between the AC 800M controller and field devices or I/O systems that utilize PROFINET industrial Ethernet protocols.

Built to withstand demanding industrial conditions, the CI871AK01 provides real-time communication, deterministic performance, and robust data exchange in automation environments. It offers a reliable and scalable solution for distributed control applications, enabling flexible plant expansions and seamless integration into existing PROFINET architectures.

Technical Specifications

Applications

The ABB CI871AK01 module is designed to facilitate high-performance Ethernet communication in a variety of industrial settings, including:

• Discrete Manufacturing – Enabling machine-to-machine communication in automotive and electronics industries.

• Process Automation – Connecting sensors, drives, and field instruments in oil & gas, chemicals, and pharmaceuticals.

• Power Plants – Integrating PROFINET-based protection relays, switchgear, and turbine controllers.

• Water and Wastewater – Enabling distributed and remote I/O access across pump stations and treatment plants.

• Material Handling Systems – Controlling conveyors, robotic systems, and sorters with deterministic performance.

• Food & Beverage – Facilitating real-time data transfer in fast-paced, hygiene-critical environments.

Key Advantages

• High-Speed Communication: Dual Ethernet ports provide fast, full-duplex data exchange across PROFINET networks.

• System Redundancy: Supports AC 800M controller redundancy for enhanced availability and fault tolerance.

• Easy Integration: Seamlessly integrates into existing ABB automation architectures using Control Builder M.

• Modular and Scalable: Fits within the modular S800 I/O design, allowing system growth and adaptability.

• Reliable Performance: Built to operate in challenging environments with wide temperature and humidity tolerances.

• Diagnostic Transparency: Real-time diagnostics with status LEDs for link, activity, and module health.

• Secure Communication: Compliant with industrial Ethernet security standards and safe configuration practices.

• Certified for Harsh Environments: Approved for marine and heavy industry applications, ensuring versatility.

Frequently Asked Questions (FAQ)

1. What is the function of the CI871AK01 module?

   It acts as a communication bridge between the AC 800M controller and field devices via PROFINET IO.

2. What types of devices can connect to CI871AK01?

   Any PROFINET IO-compatible devices such as sensors, actuators, VFDs, and distributed I/O modules.

3. Does the module support redundancy?

   Yes, both controller and network redundancy are supported for high availability systems.

4. Is this module compatible with earlier ABB systems?

   It is specifically designed for the AC 800M and S800 I/O series.

5. What software is used for configuration?

   ABB Control Builder M is used for parameter setting, diagnostics, and monitoring.

6. How is the module mounted?

   It is DIN rail mountable and integrates into the S800 I/O backplane.

7. Can this module operate in marine environments?

   Yes, it holds certifications for use in marine and offshore applications.

8. What diagnostic features are included?

   LED indicators for power, communication status, and fault diagnostics are available.

9. Is hot-swapping supported?

   Yes, the module supports hot-swap functionality within the S800 I/O system.

10. What kind of cables are required for PROFINET?

    Standard Cat 5e/6 Ethernet cables with RJ45 connectors are used for PROFINET connections.
