ABB DI831 3BSE013212R1 Digital Input
Manufacturer : ABB
ABB Model Name:DI831 3BSE013212R1
Description:Digital Input
Origin of Country: Sweden
Condition ：Brand NEW & in Stock
Payment :T/T, Western Union
Price:US$500.00
Dimensions: 20 mm x 75 mm x 50 mm
Weight: 0.8kg
Warranty : 12 months
Product Description
The DI831 is a 16 channel 48 V d.c. digital input module for the S800 I/O. The input voltage range is 36 to 60 V d.c. and the input current is 4 mA at 48 V d.c.). Each input channel consists of current limiting components, EMC protection components, input state indication LED and optical isolation barrier. The module cyclically performs self-diagnostics. Module diagnostics include:
- Process power supply supervision (results in a module failure, if detected)
- Event queue full
- Time synchronization missing.
The input signals can be digitally filtered. The filter time can be set in the range 0 to 100 ms. This means that pulses shorter than the filter time are filtered out and pulses longer than specified filter time get through the filter.
Features and benefits
- 16 channels for 48 V d.c. inputs with current sinking
- 2 isolated groups of 8 channels with voltage supervision
- Input status indicators
- Sequence of event (SOE) functionality
- Shutter filter
