AKT 0100-71455 VMEbus Backplane

The AKT 0100-71455 is a vital component in VMEbus-based systems, providing a crucial physical and electrical infrastructure. It ensures seamless communication and power delivery among VMEbus modules, enhancing overall system functionality.

Key Features

• VMEbus Standard Adherence: The AKT 0100-71455 is rigorously designed to meet VMEbus specifications. It ensures compatibility with various VMEbus modules.
• Slot Configuration: This backplane provides a specific number of standardized VMEbus slots. It offers defined mounting points for different modules and supports system expansion.
• Power Distribution: Equipped with robust power and ground connections, the backplane delivers a reliable electrical supply to all VMEbus modules.
• Signal Routing: The AKT 0100-71455 facilitates efficient, high-speed transmission of data, control, and clock signals among modules. This feature ensures smooth system operation.
• Thermal Management: The backplane includes effective cooling mechanisms. These dissipate heat from modules, maintaining optimal temperatures and system stability.

Functions

• Physical Interconnection: The backplane provides a sturdy mechanical framework and precise electrical connectors. It securely houses and connects VMEbus modules, forming the system’s core structure.
• Power Delivery: It distributes regulated power to each VMEbus module. This distribution ensures consistent electrical supply for reliable performance.
• Signal Transmission: The AKT 0100-71455 enables high-speed, low-latency communication between modules. It routes address, data, control, and clock signals effectively.
• Grounding: The backplane establishes a common ground reference for the system. This minimizes electrical noise and interference, enhancing signal integrity.
