GE IC697MDL250 Product Overview

GE IC697MDL250 is an intelligent switch input module launched by General Electric,designed specifically for industrial automation systems,supporting high-density signal acquisition and logic control.Its core functions include dual redundant power supply,software anti jitter processing,and high-speed communication,suitable for scenarios such as power systems,intelligent manufacturing,and energy management,with high reliability and strong anti-interference ability.

Main features and advantages

Dual redundant power supply design

The GE IC697MDL250 is powered by dual 24V DC power supplies,with a wide voltage range of 18V to 30V.Even if a single power supply fails,it can continue to operate,ensuring system stability.

High density signal processing

The module provides 16 channel switch input(some variants support 32 channels),supports software debounce function,can eliminate signal jitter interference,and improve data accuracy.

High speed communication and protocol compatibility

Integrated dual RS485 interface,supports Modbus protocol,communication speed up to 125kbps,can quickly interact with PLC and DCS systems,and adapt to industrial automation network architecture.

Strong isolation and security

The input signal is completely isolated from the CPU,with an isolation withstand voltage of 1500V,effectively suppressing electromagnetic interference and complying with industrial environmental safety standards.

Flexible expansion and maintenance

Supports live plugging and unplugging,allowing for module replacement without the need for power outage,reducing downtime.The operating status and signal status are indicated by LED for real-time monitoring.

technical specifications

Parameter item specification value

Input 16 points(standard)/32 points(variant)

Input type numerical quantity(dry contact/active)

Working voltage 24V DC(dual redundant)

Power input range 18V~30V

Communication interface RS485(dual channel)

Communication protocol Modbus

Communication speed 125kbps

Isolation voltage withstand 1500V

Working temperature-25°C to 70°C

Protection level IP20

Dimensions(length x width x height)approximately 120mm x 90mm x 58mm

application area

Industrial control system

Used for signal acquisition of DCS(distributed control system)and PLC(programmable logic controller),such as power plant equipment monitoring,chemical plant liquid flow control,etc.

Intelligent manufacturing

Real time acquisition and logical execution of sensor signals in automotive manufacturing,robot control,and logistics sorting systems.

energy management

Support substation switch status monitoring and automation control of solar/wind power generation systems.

infrastructure

Used for controlling signal lights in rail transit,monitoring pump stations in municipal water supply systems,and other scenarios.
