Eaton NZMN2-A250-NA 2 Product Overview

The Eaton NZMN2-A250-NA 2 is a molded case circuit breaker (MCCB) designed for use in distribution and industrial control applications. It is a 3-pole, 250A MCCB with a thermal-magnetic trip mechanism and a short-circuit breaking capacity of 50 kA at 400 V AC. The NZMN2-A250-NA 2 is part of the Eaton NZM series of MCCBs, which are designed to provide reliable and economical circuit protection for a wide variety of applications.

Key features of the Eaton NZMN2-A250-NA 2 include

• Thermal-magnetic trip mechanism for overload and short-circuit protection
• Short-circuit breaking capacity of 50 kA at 400 V AC
• Quick-make, quick-break contacts for reliable operation
• Visible indication of trip status
• Tamper-proof design to prevent unauthorized operation
• Wide range of accessories available

Specifications

• Amperage rating 250 A
• Voltage rating 690 V AC, 750 V DC
• Trip type Thermal-magnetic
• Circuit breaker type Molded case
• Frame size NZM2
• Class H
• Accessories Wide range available
• Adjustment range short-circuit release 1500-2500A
• Setting Range Ol Protector 200-250A
• Short-circuit breaking capacity 50 kA
• Interrupt rating 50 kA
• Connection Screw
• Overload range 200-250A
• Number of poles 3

Additional features

• The Eaton NZMN2-A250-NA 2 is UL and CSA listed.
• The Eaton NZMN2-A250-NA 2 is IEC 60947 compliant.
• The Eaton NZMN2-A250-NA 2 is backed by Eaton’s global support network.

Applications

• The Eaton NZMN2-A250-NA 2 is typically used in distribution and industrial control applications, such as
• Feeders
• Branch circuits
• Motor circuits
• Lighting circuits
• Backup generators
