GE IC695NIU001 Detailed Introduction

GE IC695NIU001 communication module realizes high-speed and stable data transmission between devices through Ethernet interface,providing reliable communication solutions for various industrial applications.It is suitable for many modern industrial fields such as electricity,oil,mine hoisting,ports,heating,gas,water supply,sewage treatment,metallurgy,papermaking,textile,chemical industry,etc.

Product Features

Ethernet interface:supports high-speed data transmission to ensure real-time communication between devices.

Comprehensive data exchange:By exchanging Ethernet global data(EGD),IC695NIU001 module can realize data sharing and control between master devices.During each data exchange process,it also provides controller status information to ensure the stable operation of the system.

Real-time clock and upgradeable firmware:It has a battery-powered real-time clock function that can accurately record time information.The upgradeable firmware in the system enables the module to adapt to changing application needs and maintain its technological advancement.

Multiple communication ports:In addition to the Ethernet interface,RS-232 and RS-485 serial communication ports are also provided to facilitate connection and communication with other devices.

Powerful diagnostic and communication services:Equipped with comprehensive station diagnostic tools,it can monitor and diagnose system status in real time.IP/TCP communication services through SRTP ensure reliable data transmission.

Flexible programming and expansion capabilities:Supports multiple programming languages​​and has optional local logic with a capacity of 20 KB,providing users with greater programming flexibility.In addition,it can be expanded with 90-30 series and RX3i PacSystems modules to meet the needs of different applications.

Excellent anti-interference ability:Shielding with conductive and magnetic materials is used to protect the main components such as power transformers,CPUs,programmers,etc.to prevent external interference.At the same time,various forms of filtering measures are used to reduce high-frequency interference and mutual influence between modules.

Easy to install and maintain:The modular structure is adopted to facilitate rapid repair in the event of a fault.Once a module fails,it can be quickly replaced to restore the system to normal operation.

Technical parameters

Input voltage range:12-48VDC

Output voltage range:5VDC

Output current:Maximum 10A

Efficiency:Greater than 90%

Dimensions:170mm x 105mm x 32mm

Weight:Approximately 120g

Operating temperature:-20°C to+50°C

Storage temperature:-40°C to+70°C

Ambient humidity:5%to 95%relative humidity(no condensation)

CPU:32-bit RISC processor
