Emerson KJ2221X1-EA1.1 Product Overview

The Emerson KJ2221X1-EA1.1 is a SISNET repeater carrier module from Emerson’s DeltaV SIS (Safety Instrumented System) solution. It is a crucial component of the SISNET network, responsible for transmitting safety-critical signals between SISNET devices and the DeltaV control system.

The KJ2221X1-EA1.1 ensures the reliable and timely transfer of safety data, safeguarding critical processes from hazardous conditions.

Key Features

• Dual-channel redundancy The KJ2221X1-EA1.1 features dual-channel redundancy, providing a backup communication path in case of a single channel failure. This redundancy ensures the high availability and integrity of safety signals.

• Fault detection and isolation The module incorporates advanced fault detection and isolation mechanisms to identify and isolate faulty components, preventing them from compromising the integrity of the SISNET network.

• High-speed communication The KJ2221X1-EA1.1 supports high-speed communication, enabling rapid transmission of safety data between SISNET devices and the DeltaV control system. This speed is critical for ensuring timely responses to safety events.

• Robust construction The module is housed in a rugged enclosure designed to withstand harsh industrial environments, ensuring reliable operation in demanding conditions.

• Easy installation and maintenance The KJ2221X1-EA1.1 is designed for easy installation and maintenance, minimizing downtime and simplifying maintenance procedures.

Specifications

• Power supply 12.6 VDC, 8 A
• Communication protocol SISNET
• Operating temperature 0 to 60°C (32 to 140°F)
• Protection rating IP20
• Dimensions 25.5 cm x 20 cm x 9.5 cm (10.04 in x 7.87 in x 3.74 in)
• Weight 0.8 kg (1.76 lb)

Applications

The Emerson KJ2221X1-EA1.1 is specifically designed for use in safety instrumented systems (SIS) in various industries, including

• Oil and gas Protecting oil and gas production, transportation, and refining processes from hazardous conditions.

• Chemical processing Ensuring the safety of chemical manufacturing processes, including reactors, pipelines, and storage tanks.

• Power generation Safeguarding power plants from potential hazards, such as boiler explosions and turbine failures.

• Pharmaceutical manufacturing Maintaining safety in pharmaceutical production processes, including bioreactors and filling lines.

• Pulp and paper Protecting pulp and paper mills from fire, explosions, and other safety risks.

Additional Features

• The Emerson KJ2221X1-EA1.1 is certified for use in hazardous locations.

• The module supports both local and remote configuration and maintenance options.

• It is part of Emerson’s DeltaV SIS solution, which provides a comprehensive safety instrumented system for various applications.
