XYCOM WS2786291 UNMP Product Introduction

XYCOM WS2786291 UNMP is an industrial grade network communication module designed specifically for real-time data transmission and protocol conversion in harsh environments. This module supports multi protocol compatibility (such as TCP/IP, Profinet, EtherCAT), integrates high-speed Ethernet interfaces and fiber optic communication functions, and is suitable for scenarios such as automation systems, rail transit, energy monitoring, etc. that require extremely high network stability.

Main features and advantages

High bandwidth and low latency

Supports 10/100/1000Mbps Ethernet interfaces, combined with hardware acceleration technology, to achieve data transmission latency of less than 1ms, meeting real-time control requirements.

Industrial grade anti-interference design

Adopting a shielded shell and EMC protection technology, it can adapt to a wide temperature range of -40 ℃ to 70 ℃, with anti electromagnetic interference ability reaching Class B level, ensuring stable operation under harsh working conditions.

Multi protocol flexible adaptation

The built-in protocol stack supports industrial communication protocols such as Profinet, Modbus TCP, EtherCAT, etc., allowing seamless integration with PLC, SCADA systems, and third-party devices.

Redundant communication guarantee

Equipped with dual fiber optic ports (SFP interfaces), supporting redundant ring network configuration, automatically switching communication paths in case of single point failure, and improving system reliability.

Modular expansion capability

Scalable storage and encryption module through VMEbus or PCIe interface, adaptable to different security levels and storage requirements.

Technical specifications

Parameter item specification description

Communication interface 4 × 1000Mbps Ethernet (including dual fiber SFP interface)

The protocol supports TCP/IP, Profinet, EtherCAT, Modbus TCP

Power input 24VDC, redundant power supply (supports dual power supply)

Physical dimensions VMEbus single height/double width standard size

Working temperature range -40 ℃ to 70 ℃

Seismic/Impact Resistance IEC 61373 Standard (Railway Applications)

application area

Industrial automation system

As the core communication node of distributed control network, it connects PLC, sensors and actuators to achieve millisecond level real-time data exchange.

Rail Transit Control

Support data synchronization between onboard and ground equipment to meet high reliability communication requirements, such as signal control and passenger information systems.

Energy and power monitoring

Used for substation automation systems to achieve remote equipment status monitoring and fault diagnosis.

Intelligent warehousing and logistics

Integrate AGV (Automated Guided Vehicle) and warehouse management system, optimize path planning and resource scheduling through high-speed network.
