BENTLY 350015-05-05-00 Product Introduction

The BENTLY 3500/15-05-05-00 power module is designed for high-voltage AC/DC power applications and has wide applicability and high reliability.It is suitable for various industrial automation and machinery protection systems,especially in turbine TSI(Turbine Supervisory Instrumentation)monitoring systems.

Main Features

Wide input voltage range:The power module is able to accept AC input voltages from 85 Vac to 264 Vac,enabling it to adapt to power requirements in different voltage environments.

Multiple DC output options:Provides a variety of DC output options,including VDC+8.5v,+21v,-31v,etc.,to meet the power requirements of different devices.

High reliability design:Adopts high reliability design and can operate stably for a long time in harsh industrial environments.

Compact size and moderate weight:Easy to install and integrate into various equipment,saving space.

High compatibility and customizability:It is compatible with a variety of monitoring systems,including the Bently Nevada Mechanical Condition Monitoring System,and is also suitable for other industrial applications that require high-voltage power.At the same time,it can also be customized according to actual needs to meet specific power requirements and system configurations.

Technical Specifications

Operating voltage:Typically 220V(but the specific input voltage range is as mentioned above).

Output frequency:May vary depending on the specific application,but the general module will provide a stable DC output.

Operating temperature range:-22 to 150°F(-30 to 65°C).

Humidity range:95%,non-condensing.

Installation position:The 3500/15 power supply is a half-height module and must be installed in the designated slot on the left side of the rack.

Application field

The BENTLY 3500/15-05-05-00 power supply module is widely used in the field of industrial automation,especially in the energy,oil and gas,manufacturing and other industries.It can be used to monitor and control key equipment to ensure the stability and efficiency of the production process.
