WOODWARD 8200-1302 Servo position Controller Product Introduction

Woodward 8200-1302 is a high-performance servo position controller designed for precision control applications in the industrial and energy sectors. The following is a detailed introduction to the product:

Product Overview

model: 8200-1302

Type: Servo Position Controller

Brand: Woodward

Purpose: Used to adjust the position of servo valves, actuators, or other mechanical components, widely used in fields such as power generation, oil and gas, and industrial automation.

Main features

Accurate position control

Support closed-loop position control, utilizing high-resolution feedback mechanism to ensure high-precision motion positioning.

Compatibility with multiple input signals

Compatible with analog, current (such as 4-20mA), and voltage (such as 0-10V) input signals, suitable for various control systems.

Flexible output configuration

Supports multiple output modes (such as PWM, stepper signals) to meet the driving requirements of different servo devices.

Robustness and reliability

Industrial grade design with anti vibration, anti impact, and anti electromagnetic interference capabilities, suitable for harsh working environments.

Self diagnostic function

Built in self diagnosis and status monitoring functions can quickly detect faults and issue alarms, improving the reliability of system operation.

Technical specifications

Input signal type:

Voltage input: 0-10V

Current input: 4-20mA

Digital signal input: switch quantity

Output signal type:

Analog output: 0-10V, 4-20mA

Digital output: PWM、 Switching quantity

Control mode:

Closed loop position control

Open loop position drive

Power requirements:

24V DC (industrial standard power supply)

Working temperature range:

-40 ° C to+70 ° C

Installation method:

DIN rail installation or panel installation

Communication interface:

RS-485, Modbus or CAN bus (specific supported protocols need to refer to model details)
