ABB REF615 HBFEAEAGNDA1ABA1XG Detailed Introduction

ABB REF615 HBFEAEAGNDA1ABA1XG is a feeder protection and measurement and control device produced by ABB,belonging to the ABB Relion®615 series.The following are the details of this model.

Product Overview

Model:REF615 HBFEAEAGNDA1ABA1XG

Manufacturer:ABB

Series:Relion®615 series

Function

Feeder protection:Provides protection functions for power system feeders(such as cables or transmission lines),including overcurrent protection,short circuit protection,ground fault protection,etc.

Measurement and monitoring:Real-time monitoring of current,voltage,power and other parameters,evaluates the performance of the power system and supports system maintenance.

Communication and remote control:Equipped with communication interface,supports data exchange with other devices or systems,and realizes remote monitoring and control.

Event recording and alarm:Records system events and fault conditions,generates alarm information,and helps operation and maintenance personnel to perform fault diagnosis and system optimization.

Main features

Compact structure:adopts a removable plug-in unit design,which is convenient for quick installation and testing.

Standard configuration:provides a variety of standard configurations,which can be customized by users according to their needs.

IEC 61850 compatibility:fully supports IEC 61850 standard,supports fast GOOSE messaging and IEC 61850-9-2 LE,supports parallel redundancy protocol(PRP)and high availability seamless redundancy(HSR)protocol.

Graphic display:equipped with a large graphic display,which can display customizable single line diagrams(SLD)and support local access or access through a web browser-based human-machine interface.

Adaptive protection strategy:can automatically adjust protection parameters according to the operating conditions and changes of the power system,improving the adaptability of the system.

Technical parameters(example)

Input voltage:100-240V AC

Output voltage:24V DC

Current:5A(some configurations support 100-400A)

Frequency:50/60Hz

Dimensions:100mm x 50mm x 30mm

Weight:2KG

Application areas

Power system:used to protect feeders of public substations and industrial power systems,including radial,ring and mesh distribution networks with or without distributed generation.

Industrial users:widely used in power plants,cement,metallurgy,petrochemical,automobile,semiconductor,papermaking,tobacco and other industries.

Infrastructure:suitable for power system protection in municipal,airport,port,real estate and other industries.

Installation and configuration

Installation:should be carried out in accordance with the installation manual provided by ABB to ensure that the equipment is firmly installed and the wiring is correct.

Configuration:customized through the protection and control IED manager PCM600,supporting the creation of multi-layer logic functions using various logic elements(such as timers and triggers).

Advantages

High reliability:using advanced hardware and software design to ensure stable operation of the equipment under various working conditions.

Flexibility:supporting a variety of protection and control functions,using both sensors and traditional transformers.

Easy to maintain:with self-test and event recording functions,it is easy to quickly locate and troubleshoot.

Communication capability:integrating multiple communication protocols,it is easy to integrate with the upper system to achieve remote monitoring and management.
