The Siemens 6ES7972-0BB12-0XA0 is a PROFIBUS Connector for industrial automation networks. It provides secure and stable connections between PROFIBUS stations and the network. The connector supports high-speed communication and features a compact, robust design for space-constrained environments. Engineers use it to maintain fast, reliable data transmission in harsh industrial settings.

Technical Specifications

• Model Number: 6ES7972-0BB12-0XA0

• Type: PROFIBUS Connector

• Transfer Rate: 9.6 kbit/s to 12 Mbit/s

• Electrical Connections:

  • Two screw-type terminals for PROFIBUS cables

  • One 9-pin sub-D connector for devices

• Terminating Resistor: Built-in resistor, switchable via slide

• Cable Outlet: 90-degree outlet for tight-space installations

• Material: Plastic housing with integrated strain relief

• Dimensions: 6.8 cm x 8.0 cm x 3.2 cm

• Weight: 0.06 kg

• Operating Temperature: -25°C to +60°C

• Storage/Transport Temperature: -40°C to +70°C

• Protection Class: IP20
