Yokogawa F3AD08-6R Analog Input Modules

The Yokogawa F3AD08-6R is a high-resolution analog input module designed for industrial automation applications. It converts analog signals into digital values for processing by a control system. This module is ideal for monitoring and controlling continuous measurements such as temperature, pressure, flow rate, and level.

Key Features and Specifications

• High Resolution: The F3AD08-6R provides exceptional resolution for precise measurement, ensuring accurate data acquisition.
• Multiple Channels: It offers eight analog input channels, allowing simultaneous signal processing from multiple sensors or transmitters.
• Wide Input Range: The module supports a broad input signal range, making it adaptable to various applications.
• Isolation: Built-in isolation prevents noise and ground loops, enhancing reliability and accuracy.
• Configuration Flexibility: Configure the module through software settings to meet specific application needs.
• Compact Design: Its compact size allows easy integration into control panels and systems.
• Compatibility: Seamlessly integrates with the FA-M3 series of controllers, ensuring compatibility with Yokogawa’s automation platform.

Typical Applications

• Process Control: Use it for monitoring and controlling temperature, pressure, flow rate, and level in industrial processes.
• Data Acquisition: Collect data from various sensors for detailed analysis and monitoring.
• SCADA Systems: Integrate into supervisory control and data acquisition systems for overall plant monitoring.
• Test and Measurement: Employ it in test benches and measurement systems for accurate data acquisition and analysis.

Technical Specifications

• Number of Channels: 8
• Input Signal: Typically -10 to 10 V DC (configurable)
• Resolution: High resolution for precise measurements
• Sampling Rate: Configurable based on application needs
• Isolation: Yes, to prevent noise and ground loops
• Power Supply: Provided by the FA-M3 controller
• Dimensions: Compact, suitable for panel mounting
• Environmental Conditions: Operating temperature range and humidity specifications to be considered
