ABB TU715F TU 715F 3BDH000378R0001 I/O Terminal Unit 24 VDC

The ABB TU706F 3BDH000389R0001 is a versatile Field Bus Terminal Unit (FBU) designed for integration within ABB’s Freelance control systems. It serves as an interface to connect various field devices, such as sensors, actuators, and switches, to the control system. The TU706F is built to withstand demanding environments, offering both durability and performance.

Key Features

• Device Support: Compatible with a range of field devices including sensors, actuators, and switches.
• I/O Points: Up to 32 I/O points per unit.
• Power Supply: Operates on 24 VDC.
• Environment Rating: IP67, suitable for harsh environments.
• Installation: Easy to install and configure.
• Control System Compatibility: Works with ABB’s Freelance control systems.

Technical Specifications

• Power Supply: 24 VDC
• Power Consumption: 2.5 W
• Number of I/O Points: Up to 32
• I/O Type: Digital and analog
• Signal Range: Varies depending on I/O type
• Accuracy: 0.5%
• Response Time: Less than 1 ms
• Operating Temperature: -40°C to +70°C
• Storage Temperature: -40°C to +85°C
• Humidity: 0% to 95% RH, non-condensing
• Ingress Protection: IP67
• Dimensions: 127 x 25 x 76 mm
• Weight: 0.4 kg

Applications

• Process Control
• Manufacturing
• Building Automation
• Power Generation
• Oil and Gas
