Allen-Bradley 1784-CP Communication Cable

Allen-Bradley 1784-CP is a specialized communication cable for PLC-5 controllers. It connects the PLC-5 to programming devices and other compatible equipment, enabling data exchange and supporting programming, monitoring, and configuration tasks.

Key Features and Specifications

• Purpose: Connects PLC-5 controllers for programming and communication.
• Connectors: Typically has a 62-pin connector on one end and a 3-pin connector on the other. Configurations may vary.
• Data Transfer: Supports high-speed data transfer between the PLC-5 and connected devices.
• Compatibility: Designed specifically for PLC-5 controllers.
• Durability: Built to endure industrial environments, providing reliable performance.

Technical Specifications

• Shielding: Often includes shielding to minimize electromagnetic interference and maintain signal integrity.
• Conductor Material: Made of high-quality conductors for optimal signal transmission.
• Connector Type: Commonly features 62-pin and 3-pin connectors; other configurations might exist.

Applications

• Programming: Connects programming devices to the PLC-5 for developing and modifying control programs.
• Data Transfer: Facilitates data exchange between the PLC-5 and devices like HMIs or data historians.
• Configuration: Assists in configuring the PLC-5 and its associated modules.
• Troubleshooting: Helps diagnose and resolve issues with the PLC-5 system.

Benefits

• Reliability: Provides dependable communication between devices.
• Compatibility: Specifically engineered for PLC-5 systems.
• Durability: Designed to withstand harsh industrial conditions.
• Ease of Use: Simple to connect and configure.
