General Electric IC660BCM501 Battery Charger

High-Speed Communication: The IC660BCM501 supports high-speed data transfer across the Genius I/O network, ensuring real-time communication between field devices and controllers.

• Flexible Configuration: It supports multiple block types and can be easily configured using GE’s programming tools, reducing integration time.

• Robust Diagnostics: Advanced built-in diagnostics assist in quick fault isolation and troubleshooting, enhancing system uptime.

• Rugged Design: Engineered to perform in industrial environments with wide operating temperature ranges and resistance to electrical noise.

• Multi-Drop Capability: It supports communication with up to 31 Genius I/O blocks on a single bus, reducing wiring complexity and cost.

• Hot-Swappable: Designed for minimal downtime, allowing maintenance or replacement without halting the system.

Technical Specifications

Applications

The IC660BCM501 is widely used in industrial environments that demand distributed control systems and high-performance I/O communication, including:

• Manufacturing Automation: Communication bridge between PLCs and field I/O in automotive, packaging, and food processing plants.

• Energy and Utilities: Deployed in power distribution systems and water treatment facilities for remote I/O communication.

• Oil & Gas: Used in harsh environments such as drilling platforms and refineries where robust and reliable control is essential.

• Material Handling Systems: Facilitates coordination between multiple sensors, actuators, and controllers.

• Building Automation: For HVAC and lighting control systems that require decentralized I/O architecture.

Installation Instructions

1. Power Down System: Ensure the main power supply is turned off before installation.

2. Insert into Backplane: Slide the IC660BCM501 module into a designated rack slot and firmly seat it.

3. Connect to Genius Bus: Attach the Genius bus cable to the communication port and ensure proper termination.

4. Configure Settings: Use a handheld monitor (IC660/HHM) or PC configuration software to assign node numbers and configure the device.

5. Apply Power and Test: Power up the system, verify LED indicators, and run diagnostic checks to ensure proper communication.

FAQ(Frequently Asked Questions)

Q1: What is the function of the GE IC660BCM501 module?

A1: It acts as a communication interface between a host controller and Genius I/O blocks in a distributed control system.

Q2: How many I/O blocks can it control?

A2: It supports up to 31 Genius I/O blocks on a single bus.

Q3: Can the IC660BCM501 be hot-swapped?

A3: Yes, the module supports hot-swapping for reduced downtime.

Q4: What type of cable is used for Genius bus communication?

A4: Twisted-pair shielded cable, typically Belden 9182 or equivalent.

Q5: What tools are used to configure this module?

A5: GE’s handheld monitor (IC660/HHM) or PC-based configuration tools.

Q6: Does it require a specific rack for installation?

A6: Yes, it must be installed in a compatible GE rack system.

Q7: What diagnostic features does it include?

A7: It provides status LEDs and detailed fault codes via handheld monitors or software.

Q8: Can it be used with PLCs from other brands?

A8: While designed for GE systems, it may integrate with other PLCs via appropriate protocols, though not guaranteed.

Q9: What is the input voltage requirement?

A9: The module operates with 5V DC supplied via the backplane.

Q10: Is the module firmware upgradeable?

A10: No, firmware updates are typically not user-performed on this legacy device.
