The Foxboro B0123HE is an adjustable pressure regulator with an integrated filter, designed for industrial automation systems. It offers precise pressure control and filtration for pneumatic instruments, ensuring smooth and accurate performance in various applications.

Technical Specifications

• Manufacturer: Foxboro
• Model: B0123HE
• Product Type: Adjustable Pressure Regulator with Filter
• Supply Pressure: Up to 1.7 MPa (250 psi, 17 bar)
• Regulated Pressure: 0.5 to 60 psi
• Flow Capacity: 33.6 m³/hr at 700 kPa (100 psi, 7 bar)
• Sensitivity: 25 mmH₂O (1 inH₂O)
• Connection Size: 1/4 inch NPT
• Dimensions: 7.0 cm x 13.3 cm x 13.3 cm
• Weight: 1.81 lbs
• Mounting:
  • Two 8 mm (0.320 in) diameter holes for bracket mounting
  • Two 0.190-24 tapped holes for panel mounting
