The GE Fanuc CQPK3D200L2P-A is a 6-inch monochrome touch screen HMI (Human Machine Interface) from the QuickPanel Jr. series. It serves as an interface for operators to monitor and control industrial processes. The device is designed for reliability and ease of use, with a NEMA Type 4X/12 rating for protection against dust, water, and corrosion.

Technical Specifications

• Manufacturer: GE Fanuc
• Model Number: CQPK3D200L2P-A
• Screen Size: 5.7 inches (6 inches measured diagonally)
• Display Type: Monochrome LCD
• Resolution: 240 x 320 pixels
• Input Voltage: 24 VDC
• Communication: Modbus RTU protocol (RS485 or RS232)
• NEMA Rating: Type 4X/12, IP65 (dust, water, and corrosion protection)
• Operating Temperature Range: 0°C to 50°C (32°F to 120°F)
• Relative Humidity: 20% to 85% (non-condensing)
• Dimensions: 7.0 in x 6.0 in x 3.0 in (17.8 cm x 15.2 cm x 7.6 cm)
• Weight: 2 lbs 4.0 oz (1.0 kg)
• Software: QuickDesigner Version 3.7
