The Honeywell CC-PFB802 is a Fieldbus Interface Module (FIM) designed for seamless integration into Honeywell’s Experion Process Knowledge System (PKS). It ensures reliable communication between the control system and field devices, optimizing performance in industrial automation and process control.

General Information

• Model Number: CC-PFB802
• Type: Fieldbus Interface Module
• Networks Supported: Up to 8 Fieldbus networks
• Communication Protocol: FOUNDATION Fieldbus
• Power Supply: 24 VDC
• H1 Networks per FIM: 4
• Configurations: Non-redundant or redundant (side-by-side)
• Maximum Fieldbus Devices per H1 Network: 16
• Available Macrocycle Periods: 250 ms, 500 ms, 1 sec, 2 sec, 4 sec, 8 sec, 16 sec, and 32 sec
• Operating Temperature: -40°C to +70°C (-40°F to +158°F)
• Dimensions: 12.7 cm × 12.7 cm × 12.7 cm
• Weight: 0.8 kg
