ABB 1KHW002296R0001 Universal Digital Power Line Carrier

The ABB 1KHW002296R0001 is a universal digital power line carrier (DPLC) module designed to facilitate efficient communication between remote devices in industrial automation settings. It leverages existing power line infrastructure to transmit data, reducing the need for extra cabling and lowering installation costs.

Key Features

• Universal Operation: Supports analog and digital operation modes, ensuring compatibility with various devices and applications.
• Flexible Channel Configuration: Capable of accommodating up to three traditional analog channels of 4 kHz and/or one digital channel, covering a maximum bandwidth of 12.5 kHz.
• Software Configurability: Easily adaptable to specific application needs through software configuration.
• Rugged Design: Built to withstand harsh industrial environments, ensuring durability and reliability.

Technical Specifications

• Power Supply: 24 VDC
• Power Consumption: 2 W
• Operating Temperature: -20 to 70°C
• Protection: IP20
• Dimensions: 90 x 35 x 22 mm

Applications

The ABB 1KHW002296R0001 is ideal for a range of industrial automation applications, including:

• Remote I/O Communication: Connecting remote I/O modules to PLCs.
• Data Acquisition: Gathering data from sensors and field devices.
• Control and Monitoring: Implementing distributed control and monitoring systems.

Benefits

• Cost Reduction: Eliminates the need for additional cabling and reduces installation labor costs.
• Reliability: Uses proven communication technology for reliable operation.
• Flexibility: Adaptable to diverse applications through software configuration.
• Maintenance: Easy maintenance and troubleshooting due to its modular design.
