ABB SA801F 3BDH000011R1 power supply

This module is specifically engineered to provide safe and continuous operation in industrial control environments. It serves as a communication concentrator or gateway and plays a vital role in applications requiring backward compatibility with existing ABB infrastructures while enabling modern system expansion.

Technical Parameters

Product Applications

The ABB SA801F is widely used in various industrial sectors, particularly where ABB Advant and Symphony Plus systems are employed. Typical application areas include:

• Power Generation Plants – for interfacing control units with distributed control systems (DCS).

• Oil and Gas – integration of legacy controllers into modern architectures.

• Chemical and Petrochemical Plants – data collection and system coordination.

• Water and Wastewater Management – supervisory data transfer across control networks.

• Process Automation Systems – where a unified interface between subsystems is required.

Product Advantages

• Legacy Support: Seamlessly integrates with Advant Master systems, preserving investments in older infrastructure.

• High Reliability: Designed for industrial-grade durability with robust EMC immunity and fault tolerance.

• Redundant Communication: Dual-port support ensures uninterrupted communication and failover safety.

• Flexible Protocols: Multi-protocol support allows versatile deployment across diverse networks.

• Compact Design: Space-efficient for control cabinets, with minimal power requirements.

• Easy Maintenance: Module-based design simplifies replacement and diagnostics.

• Secure Data Handling: Ensures data integrity and real-time processing.

• ABB Ecosystem Compatibility: Fully optimized for ABB’s Symphony Plus environment.

FAQs

Q1: What is the main function of the ABB SA801F module?

A1: It acts as a communication gateway, connecting older Advant Master controllers to the Symphony Plus system.

Q2: Does it support redundant communication?

A2: Yes, it includes dual communication channels to ensure high availability and failover support.

Q3: Is the SA801F compatible with non-ABB systems?

A3: Primarily designed for ABB platforms, though it may interface with other systems through standard protocols like Modbus TCP/IP.

Q4: What kind of protocols are supported by the SA801F?

A4: It supports MODBUS, TCP/IP, and proprietary ABB protocols.

Q5: Can the module be mounted on a DIN rail?

A5: Yes, it supports both DIN rail and cabinet mounting options.

Q6: What is the operating voltage of the SA801F?

A6: It operates on a 24 V DC power supply.

Q7: Is it suitable for harsh environments?

A7: Yes, it is designed for industrial use with wide temperature and humidity tolerance.

Q8: Does ABB offer software tools for configuring the SA801F?

A8: Yes, ABB provides configuration utilities as part of the Symphony Plus engineering suite.

Q9: Is firmware upgradeable?

A9: Yes, firmware updates can be applied through ABB support tools.

Q10: How do I troubleshoot the module if communication fails?

A10: Use onboard status LEDs, diagnostic software, and system logs to identify and resolve issues.
