The YOKOGAWA UP55A-012-11-00 is a high-performance, multi-function digital controller. It delivers precision process control in various industrial applications. This controller offers advanced control algorithms, a user-friendly interface, and robust construction for reliable operation in demanding environments.

Technical Specifications

• Control Functions: PID control, advanced control algorithms
• Display: Large, easy-to-read LCD screen
• Inputs: Universal inputs for thermocouples, RTDs, voltage, and current
• Outputs: Relay, SSR drive, and analog outputs
• Power Supply: 100 to 240 V AC, 50/60 Hz
• Operating Temperature Range: 0 to 50°C (32 to 122°F)
• Dimensions: 96 mm x 96 mm x 100 mm (W x H x D)
• Mounting: Panel mounting
• Communication: RS-485, Modbus RTU
• Accuracy: ±0.1% of span
• Control Period: 0.1 to 100 seconds (selectable)
• Programming: Up to 100 program segments
• Alarms: 4 configurable alarms

Features

The YOKOGAWA UP55A-012-11-00 offers a user-friendly interface with a large LCD screen and intuitive navigation, making setup and operation easy. It supports a wide range of input types and provides multiple output options. Advanced control algorithms ensure precise and stable control for various applications. The robust construction withstands harsh industrial environments, while communication capabilities allow integration with other systems via RS-485 and Modbus RTU.
