ABB CI535V30 3BSE022162R1 SPA Server Protocol SPA Bus
Item Number:CI535V30 3BSE022162R1
Brand:ABB
Lead Time: In stock
Description:SPA Server protocol SPA Bus
Payment: T/T
Product Description
ABB CI535V30 (3BSE022162R1) is a SPA Server Protocol module for the Advant Master control system, belonging to the AC 400 series of communication modules. The ABB CI535V30 connects the Advant Controller 450 to the bus system and provides predefined circuit types for connecting drivers and INSUM MCUs.
Note: ABB CI535V30 supports multiple protocols, such as RCS protocol master station (RP570/RP571), RTU protocol slave station (RP570), and IEC 870-5-101 unbalanced secondary station.
Function & Features
- ABB CI535V30 (3BSE022162R1) acts as a server in a SPA bus network. A single SPA bus network can support up to 50 nodes.
- ABB CI535V30 (3BSE022162R1) can connect to DC and AC motor drives (such as ACS 600, DCS 600, DCS 500B) via Advant Fieldbus 100 or MasterFieldbus.
- ABB CI535V30 (3BSE022162R1) connects to the INSUM motor control unit (MCU) via the LONWORKS network on the CI572 communication module.
- ABB CI535V30 (3BSE022162R1) can also access INSUM motor control units via the LONWORKS network, and a single LONWORKS channel can connect one INSUM motor controller and up to 64 motor control units.
Specifications
| Parameter | Details |
|---|---|
| Product Model | CI535V30 |
| Part Number | 3BSE022162R1 |
| Data Exchange Mechanism | Data sending and receiving via PC elements |
| SPA Bus Node Count | Up to 50 nodes |
| Module Type | Communication Interface Module |
| Depth | 120 mm |
| Height | 20 mm |
| Width | 245 mm |
| Weight | 0.15 kg |
FAQ
Q: What is the payment method?
A: T/T
Q: Is technical support available?
A:Yes, we have a professional technical team to address technical issues.
Q: What is the warranty?
A: 1 year
Q: What is the return and exchange policy?
A: Returns or exchanges are accepted within 7 days of receiving the goods if there are any quality issues, excluding damage caused by human error or misuse.
Q:What are the available shipping methods?
A: FedEx, DHL, UPS, and others.
