ABB SDCS-AMC-DC-2 3ADT312700R0001 Control Board

The ABB SDCS-AMC-DC-2 (Part No. 3ADT312700R0001) is a high-performance control board designed for ABB’s legacy DC drive systems, particularly the DCS600 series. This control unit serves as the central processing component, managing drive operations, motor control, and communication interfaces. Engineered for reliability and precision, the SDCS-AMC-DC-2 ensures optimal performance in demanding industrial environments.

Technical Specifications

Product Applications

The SDCS-AMC-DC-2 control board is utilized in various industrial applications, including:

• Steel and Metal Processing – Managing rolling mills and processing lines.

• Pulp and Paper Industry – Controlling paper machine drives and winders.

• Power Generation – Regulating auxiliary systems and exciters.

• Cement Manufacturing – Operating kiln and mill drives.

• Mining Operations – Managing hoists, crushers, and conveyors.

• Marine Applications – Controlling propulsion and auxiliary systems.

Product Advantages

• Robust Performance: Designed for high-reliability in demanding environments.

• Advanced Processing: Equipped with a 32-bit microcontroller for precise control.

• Versatile Communication: Supports RS-485 Modbus RTU for seamless integration.

• Compact Design: Space-efficient dimensions facilitate easy installation.

• Global Compliance: Meets international standards, including IEC 61131-3.

• ABB Quality Assurance: Backed by ABB’s reputation for excellence in industrial automation.

FAQ

1. What is the primary function of the SDCS-AMC-DC-2 control board?

   It serves as the main control unit for ABB’s DCS600 series DC drives, managing motor control and communication interfaces.

2. Which drive systems are compatible with this control board?

   The SDCS-AMC-DC-2 is designed for use with ABB’s DCS600 series drives.

3. What are the input voltage requirements?

   The board operates on an input voltage of 120 – 240 V AC.

4. Does the board support Modbus communication?

   Yes, it supports RS-485 Modbus RTU communication protocol.

5. What is the operating temperature range?

   The board operates reliably within a temperature range of 0°C to +55°C.

6. Is the SDCS-AMC-DC-2 suitable for marine applications?

   Yes, it is used in marine environments for controlling propulsion and auxiliary systems.

7. What are the dimensions and weight of the board?

   The board measures 132 x 53 x 65 mm and weighs 0.09 kg.

8. Does the board comply with international standards?

   Yes, it complies with IEC 61131-3 standards.

9. Where is the SDCS-AMC-DC-2 manufactured?

   The board is manufactured in Sweden.

10. Can the board be used in new installations?

    While designed for legacy systems, it can be integrated into new installations requiring compatibility with DCS600 series drives.
