ABB DSQC609 3HAC14178-1 Robot Power Supply

The ABB DSQC609 3HAC14178-1 is a robust and reliable power supply module engineered specifically for ABB’s IRC5 robot controller systems. This unit plays a critical role in converting and distributing power to internal control boards, servo drives, feedback units, and communication modules in robotic automation environments.

Known for its stability, durability, and safety, the DSQC609 ensures continuous, regulated power delivery in high-demand industrial applications. Its compatibility with a wide range of ABB IRB-series robots makes it an essential component for maintaining controller functionality and minimizing system downtime.

Key Features

• High-efficiency power conversion for IRC5 control systems

• Supports continuous operation in harsh industrial environments

• Delivers regulated power to multiple internal subsystems

• Built-in overvoltage and short-circuit protection

• Passive and active thermal management system

• CE and RoHS certified industrial-grade electronics

• Hot-swappable in select controller configurations

• Compatible with global voltage standards (via IRC5 configuration)

Technical Specifications

Industry Applications

• Automotive Manufacturing – Powers robot controllers in welding, painting, and assembly lines

• Packaging and Logistics – Provides reliable control power to sorting and packing robots

• Electronics Production – Ensures uninterrupted operation of pick-and-place robotic arms

• Metalworking and CNC – Supports robots in high-precision machining environments

• Plastics and Molding – Maintains stable controller function for robotic injection processes

• General Industrial Automation – Powers ABB robots in smart factories and high-speed automation cells

Product Advantages

• Optimized for ABB IRC5 – Full compatibility ensures plug-and-play performance

• High Power Stability – Maintains consistent voltage even under fluctuating load conditions

• Rugged Design – Engineered to endure vibration, temperature shifts, and electrical noise

• Safe Operation – Comprehensive built-in protections guard against system faults

• Low Maintenance – Designed for extended operating life with minimal intervention

• Global Readiness – Compatible with a wide range of factory voltage standards

• Serviceable – Easily replaceable in the field; ABB offers support and spare parts

• Proven Reliability – Deployed worldwide in thousands of robot controller installations

Frequently Asked Questions (FAQ)

1. Q: What is the primary function of the DSQC609 power supply?

   A: It converts incoming AC voltage to regulated DC power for use by internal IRC5 components.

2. Q: Is the DSQC609 compatible with all ABB robot models?

   A: It is compatible with many ABB IRB series robots using the IRC5 controller, including IRB 2400, 4400, 4600, and others.

3. Q: Can the DSQC609 be replaced in the field?

   A: Yes, it is a field-replaceable unit when following ABB’s standard service procedures.

4. Q: Does this unit support hot-swapping?

   A: In some configurations with power interlocks, it may support live swap with proper safety precautions.

5. Q: What protections are built into the DSQC609?

   A: It includes overvoltage, overcurrent, and thermal shutdown protection.

6. Q: Does this power supply require external cooling?

   A: No, it is passively cooled with support from the controller’s integrated fan system.

7. Q: What certifications does it meet?

   A: CE, RoHS, and it complies with international EMC and safety standards.

8. Q: How can I check if my DSQC609 is functioning properly?

   A: Use ABB’s RobotWare software or monitor system diagnostics through the controller display.

9. Q: Can this unit be refurbished or repaired?

   A: Yes, ABB offers factory refurbishment and certified repair options.

10. Q: Where can I source this unit?

    A: Through ABB’s global distribution network or authorized service partners.
