ABB SDCS-AC-CON-2 3ADT220072R0012 Control Board

The ABB SDCS-AC-CON-2 (Part Number: 3ADT220072R0012) is an advanced control board designed specifically for use within ABB’s range of DCS industrial drive systems. It plays a critical role in enabling reliable AC drive communication and interface control. As part of the ABB DCS500 and DCS800 series, this board ensures seamless integration between the drive and connected control devices, providing consistent signal conversion, data processing, and command execution.

This control board is engineered for harsh industrial environments and supports high-precision operations in complex automation systems. Known for its robust performance, longevity, and compatibility, the SDCS-AC-CON-2 continues to be a trusted choice in retrofit and modern automation applications worldwide.

Technical Specifications

Product Applications

The SDCS-AC-CON-2 board is widely used across several industries and environments, including:

• Steel and metal processing plants – for control of large rolling mill drives.

• Pulp and paper mills – supporting variable-speed drives in processing systems.

• Chemical industries – used in precision mixing and pumping systems.

• Marine and offshore – in propulsion control and auxiliary systems.

• Mining operations – ensuring robust control in hoist and conveyor applications.

• Power generation – integrated in turbine auxiliary systems or blower drives.

Product Advantages

• Seamless Compatibility: Fully compatible with DCS500 and DCS800 drive families, reducing integration time.

• Industrial Grade Durability: Built to last in high-vibration, high-temperature environments.

• Optimized Signal Conversion: Ensures precise control and minimal delay in drive responses.

• Trusted Brand: Backed by ABB’s decades of experience in automation and drive technology.

• Serviceability: Readily available in ABB’s global service network for replacement or diagnostics.

• Retrofit-Friendly: Ideal for system upgrades where older boards have become obsolete.

FAQ

1. What is the primary function of the SDCS-AC-CON-2 board?

   It serves as a control and communication interface between ABB drives and external control systems.

2. Is the SDCS-AC-CON-2 compatible with DCS800 drives?

   Yes, it supports both DCS500 and DCS800 drive families.

3. Can I install the board outside the drive cabinet?

   No, it must be installed inside a protected environment like a drive enclosure.

4. Is firmware update required for this board?

   Generally, it uses fixed firmware, but updates may be available depending on application.

5. How can I replace a damaged SDCS-AC-CON-2?

   Follow ABB’s service manual, ensuring power is off and safety protocols are followed.

6. Does this board support fiber optic communication?

   Yes, depending on configuration and drive system setup.

7. What is the life expectancy of this board?

   Typically over 10 years if operated under recommended environmental conditions.

8. Can this board be used in new system installations?

   Yes, particularly when using ABB DCS series drives in new systems or retrofits.

9. Is this board RoHS compliant?

   Yes, it meets RoHS and CE compliance standards.

10. What tools are needed for installation?

    A standard insulated screwdriver and ESD protection gear are recommended.
