OVATION 1C31194G03 Valve Positioner

Its rugged design supports high reliability and long-term operational stability, even in harsh industrial environments. This module is widely used in industries such as power generation, water treatment, chemical processing, and oil & gas.

Technical Specifications

Product Advantages

• High Precision: With 12-bit resolution, the module offers smooth and accurate analog control ideal for critical process variables.

• Flexible Output Options: Supports both current (4–20 mA) and voltage (0–10 V) outputs, adaptable to various field device requirements.

• Isolated Channels: Each channel is electrically isolated, preventing cross-talk and enhancing reliability and safety.

• Integrated Diagnostics: Onboard diagnostics help in real-time fault detection and minimize downtime.

• Durable Design: Engineered for industrial conditions with wide temperature tolerance and resistance to vibration and electrical noise.

• Seamless Integration: Fully compatible with Emerson Ovation DCS architecture, simplifying deployment and reducing engineering time.

Product Applications

• Power Plants: For controlling analog actuators such as dampers, valves, and regulators in turbine and boiler systems.

• Water and Wastewater Treatment: Used in chemical dosing, flow control, and level management.

• Chemical Processing: Provides analog control for metering pumps, blend ratios, and reactor temperatures.

• Oil and Gas: Supports valve actuation and motor control in remote or hazardous environments.

• Pulp and Paper: Regulates speed and position control for rotary machinery and paper lines.

FAQs

Q1: What is the main function of the 1C31194G03 module?

A1: It translates digital commands from the Ovation DCS into analog signals for field devices like valves and actuators.

Q2: Can this module output both voltage and current?

A2: Yes, it supports both 4–20 mA and 0–10 V analog output formats, and it can be configured accordingly.

Q3: How many output channels does the module provide?

A3: The 1C31194G03 offers 8 individually isolated analog output channels.

Q4: Is this module hot-swappable?

A4: No, for safety and system integrity, it should be replaced or installed with power off and following Ovation system procedures.

Q5: What makes this module suitable for power generation environments?

A5: Its accuracy, isolation, and compliance with industrial certifications make it ideal for sensitive analog control in power facilities.

Q6: What diagnostic features does the module offer?

A6: It includes internal diagnostics for output channel status, overcurrent conditions, and internal faults, which are reported to the control system.

Q7: Is any special tool required for configuring the output range?

A7: Configuration is typically done through the Ovation control system interface, so no separate hardware tool is needed.

Q8: How is the module mounted in the system?

A8: It mounts onto a standard Ovation I/O base or carrier and connects to the Ovation backplane for power and communication.

Q9: Can this module operate in outdoor environments?

A9: It is intended for installation in controlled cabinet environments. For outdoor use, enclosure protection is required.

Q10: What kind of isolation does this module have?

A10: Each channel is isolated from other channels and from the system to prevent signal interference or ground loops.
