Yokogawa SNT501-53 Optical Bus Repeater Module

The Yokogawa SNT501-53 is a highly reliable optical bus repeater module designed to enhance communication within complex industrial control networks. As part of the STARDOM and CENTUM series safety and control systems, this module plays a critical role in converting electrical ESB bus signals into optical signals for long-distance, interference-free transmission and reconversion at the destination point.

With its advanced optical interface, the SNT501-53 ensures stable data transfer, reduced noise susceptibility, and simplified network scalability. It is widely deployed in industries such as power generation, petrochemical processing, refining, and advanced manufacturing, where high-speed and uninterrupted communication is crucial.

Product Specifications

Product Applications

• Long-Distance Data Transmission

  Ensures reliable optical communication over distances up to 5 km or 10 km with advanced configurations, making it ideal for large industrial facilities.

• Fault Isolation in Critical Systems

  Provides effective electrical isolation to prevent damage or downtime caused by electromagnetic interference.

• Scalable Network Designs

  Supports cascaded repeater setups, enabling expansion of existing systems without major hardware overhauls.

• High-Reliability Industrial Processes

  Optimized for industries such as power plants, petrochemical plants, and manufacturing environments that demand non-stop, stable communication.

• Legacy System Integration

  Allows seamless upgrades from older ESB bus infrastructures to optical-based systems without requiring full system replacement.

Product Advantages

1. High Transmission Stability – Maintains consistent and reliable data flow even in noisy industrial environments.

2. Extended Range – Supports up to 10 km in optimized setups, perfect for extensive facilities.

3. Superior Noise Immunity – Optical transmission eliminates signal degradation from electromagnetic interference.

4. Flexible Topology – Compatible with star, chain, and hybrid network configurations.

5. Compact, Lightweight Design – Space-saving module with just 0.3 kg weight for easy installation.

6. Low Power Consumption – Consumes only 0.5 A, making it energy efficient.

7. Cascadable for Expansion – Allows up to two repeater stages for flexible system scaling.

8. Robust Build Quality – Designed to perform reliably in harsh industrial conditions.

9. Seamless Compatibility – Fully integrates with Yokogawa control and safety platforms.

10. Cost-Effective Solution – Enables cost-efficient upgrades without replacing the existing infrastructure.
