Yokogawa AAI143-h00 Analog Input Module

The Yokogawa AAI143-H00 is an Analog Input Module designed for high-precision data acquisition in industrial automation systems. As part of Yokogawa’s renowned I/O module series, the AAI143-H00 offers reliable and accurate analog signal processing, making it an essential component for monitoring and controlling various industrial processes.

Product Specifications

Product Applications

The AAI143-H00 Analog Input Module is utilized across various industries for precise data acquisition and process control:

• Chemical Processing: Monitoring temperature, pressure, and flow rates to ensure optimal reactions and safety.

• Oil and Gas: Measuring pipeline pressures and temperatures for efficient extraction and transportation.

• Power Generation: Tracking generator outputs and environmental conditions to maintain system stability.

• Water Treatment: Assessing water quality parameters such as pH and turbidity for regulatory compliance.

• Pharmaceuticals: Ensuring precise environmental conditions in manufacturing processes to maintain product quality.

• Food and Beverage: Monitoring storage and processing temperatures to meet health and safety standards.

Product Advantages

• High Accuracy: 16-bit resolution ensures precise measurement of analog signals, critical for process control.

• Flexible Input Ranges: Supports multiple signal types (4-20 mA, 1-5 V, 0-10 V, ±10 V), accommodating diverse sensors and devices.

• Robust Isolation: 1500 V AC isolation protects the system from electrical noise and potential damage.

• Efficient Sampling: High sampling rate allows for real-time monitoring and quick response to process changes.

• Compact Design: Small footprint facilitates easy integration into existing control systems without requiring extensive space.

• Wide Operating Range: Designed to function effectively in harsh industrial environments with extreme temperatures and humidity levels.

FAQ

1. What types of input signals does the AAI143-H00 support?

   The module supports 4-20 mA, 1-5 V, 0-10 V, and ±10 V input signals.

2. How many input channels are available on this module?

   It offers 16 single-ended or 8 differential input channels.

3. What is the resolution of the AAI143-H00?

   The module provides a 16-bit resolution for precise measurements.

4. Is there isolation between channels and the system?

   Yes, there is 1500 V AC isolation between the input channels and the system.

5. What is the operating temperature range for this module?

   The module operates effectively between -20°C to 60°C (-4°F to 140°F).

6. Can the AAI143-H00 be used in high humidity environments?

   Yes, it functions in humidity levels ranging from 5% to 95% RH (non-condensing).

7. What are the dimensions and weight of the module?

   The module measures 107.5 × 32.8 × 130 mm and weighs 0.3 kg.

8. What is the power consumption of the AAI143-H00?

   It consumes approximately 5 W of power.

9. Is the module compatible with other Yokogawa systems?

   Yes, it is designed to integrate seamlessly with Yokogawa’s control systems.

10. How is the module mounted within a control system?

    The module is typically mounted on a standard DIN rail within control cabinets.
