Honeywell LG1093AA24 Flame Sensor
Manufacturer: Honeywell
Product Number: LG1093AA24
Category: Flame Detector / Flame Sensor
Detection Method: UV radiation detection from hydrocarbon flames
Response Time: 0.1 second typical
Operating Temperature: -40°F to +350°F (-40°C to +177°C)
Mounting Interface: 3/4-inch internal NPT
Cable Connection: Teflon shielded cable with 1-inch outside conduit thread
Max Cable Distance: Up to 1000 feet
Application: Gas turbine combustion systems, marine power generation, pumping stations, industrial processes
Certifications: ATEX, CE (EMC 89/336/EEC, LVD 73/23/EEC)
Product Description
The Honeywell LG1093AA24 is an ultraviolet (UV) flame detector designed for use in burner control units, particularly in gas turbines. It plays a vital role in flame safety systems by detecting the presence or absence of a flame using ultraviolet radiation. This information is then transmitted to the burner control unit, ensuring the safe and efficient operation of the burner in industrial and commercial heating applications.
Technical Specifications
Model Number: LG1093AA24
Type: Ultraviolet Flame Detector
Manufacturer: Honeywell
Detection Range: 1850 to 2650 angstroms (UV light)
Mounting Interface: 3/4 inch internal NPT
Cable Type: Teflon shielded cable with 1-inch external conduit thread
Operating Temperature Range: -40°F to +350°F
Window Pressure Rating: 150 psig at 400°F
Cable Length: 4.9 meters (16 ft) standard; other lengths available
Weight: 2.35 lbs
Application: Gas turbine flame monitoring systems
Loading comments...
Honeywell LG1093AA24 Flame Sensor
Manufacturer: Honeywell
Product Number: LG1093AA24
Category: Flame Detector / Flame Sensor
Detection Method: UV radiation detection from hydrocarbon flames
Response Time: 0.1 second typical
Operating Temperature: -40°F to +350°F (-40°C to +177°C)
Mounting Interface: 3/4-inch internal NPT
Cable Connection: Teflon shielded cable with 1-inch outside conduit thread
Max Cable Distance: Up to 1000 feet
Application: Gas turbine combustion systems, marine power generation, pumping stations, industrial processes
Certifications: ATEX, CE (EMC 89/336/EEC, LVD 73/23/EEC)
Product Description
The Honeywell LG1093AA24 is an ultraviolet (UV) flame detector designed for use in burner control units, particularly in gas turbines. It plays a vital role in flame safety systems by detecting the presence or absence of a flame using ultraviolet radiation. This information is then transmitted to the burner control unit, ensuring the safe and efficient operation of the burner in industrial and commercial heating applications.
Technical Specifications
Model Number: LG1093AA24
Type: Ultraviolet Flame Detector
Manufacturer: Honeywell
Detection Range: 1850 to 2650 angstroms (UV light)
Mounting Interface: 3/4 inch internal NPT
Cable Type: Teflon shielded cable with 1-inch external conduit thread
Operating Temperature Range: -40°F to +350°F
Window Pressure Rating: 150 psig at 400°F
Cable Length: 4.9 meters (16 ft) standard; other lengths available
Weight: 2.35 lbs
Application: Gas turbine flame monitoring systems
