ABB FAU800 C10-11010 Measure IT Flame Analysis Unit
Item Number:FAU800 C10-11010
Brand: ABB
Lead Time: In stock
Description:Flame Analysis Unit
Payment: T/T
Product Description
ABB FAU800 C10-11010 (Measure IT Flame Analysis Unit) is the latest generation of cutting-edge flame analysis equipment launched by ABB. It is used to monitor the flame status of the burner in real time to ensure combustion safety and prevent danger caused by flame extinction. FAU800 supports a variety of ABB flame detection equipment (such as DFS flame scanning head, 4-20mA/0-5V sensor, ion flame monitoring rod, etc.).
Function & Features
- Parameter customization switching: ABB FAU800 can customize detection parameters for different fuels (such as coal and oil) through two digital input channels.
- Signal value acquisition and judgment: ABB FAU800 analyzes the signal generated by the flame detector in real time, compares it with the preset functional limit, and judges whether the current signal is within the safe range.
- Signal quality evaluation: ABB FAU800 measures the signal quality to reflect the change of the burner flame. For example, the change of the quality value before the flame goes out can be used as an early warning indicator to help predict potential problems.
- No flame state identification: When ABB FAU800 detects a system fault or the signal exceeds the preset limit, it generates a "no flame" signal to indicate an unsafe working condition.
Specifications
| Parameter | Specification |
|---|---|
| Model | FAU800 |
| Ordering Number | C10-11010 |
| Flame Failure Relay Drop-Out | Configurable 0.1 to 2.5 seconds |
| Flame Relay(s) | Three total, each with Form C contacts |
| Flame Relay Contact Ratings | 250 Vac, 3A, 750 VA; 220Vdc, 300 mA, 66 watts |
| Fault Relay Contact Ratings | 250 Vac, 3A, 750 VA; 220Vdc, 300 mA, 66 watts |
| Analog Flame Signal Outputs | Two channels of 4-20 mA signals. Each channel can independently monitor Intensity, Frequency, Quality, or AC Amplitude |
| Serial Data Communication | Two galvanically isolated RS-485 interfaces (fully independent for redundancy) |
| Serial Data Format | MODBUS (default), PROFIBUS (optional) |
| Self-Checking Time Cycle | Electronics checked every 0.1 seconds |
| Case Dimensions | 13 cm (height) × 12 cm (length) × 11 cm (width) |
FAQ
Q: What is the brand?
A: ABB
Q: What is the type?
A: Flame Analysis Unit
Q: What is the warranty?
A: 1 year
Q: Where is the shipping location?
A: Xiamen
Q: What is the payment method?
A: T/T
