The Allen-Bradley 1771-HS3A is a versatile servo controller module designed for use with Allen-Bradley PLC-5 systems. It controls up to three servo axes, making it an essential component for various automation applications.

Key Features and Specifications

3-Axis Servo Control: The module controls three servo motors simultaneously, enabling complex motion profiles and synchronization.

Compatibility: It integrates seamlessly with Allen-Bradley PLC-5 components, such as the 1771-PS7 power supply.

Applications: Typically, it controls devices like solenoids, indicators, and AC motor starters.

Flexibility: The module offers multiple configuration options, allowing adaptation to different automation needs.

Robustness: It withstands industrial environments, ensuring reliable operation.

Technical Specifications

Although specific technical details vary by configuration and firmware, here are some general specifications:

Number of Axes: Controls up to 3 axes.

Power Supply: Requires the Allen-Bradley 1771-PS7 power supply.

Communication: Communicates directly with the PLC-5 via the PLC-5 bus.

Mounting: Designed for rack mounting within the PLC-5 system.

Environmental: Meets industrial standards for temperature, humidity, and vibration.
