The ABB SYN5011a-P is a robust synchronization transformer designed for safe and efficient generator or power system paralleling. It accurately measures key parameters and ensures optimal synchronization before connecting systems.

Key Functions

• Measurement: Measures voltage, current, frequency, and phase angle from various electrical sources.
• Comparison: Compares measured parameters to assess synchronization conditions.
• Control Signals: Generates signals to start or halt synchronization based on comparison results.

Benefits

• Safe and Reliable Synchronization: Avoids system damage and disruptions.
• Improved System Performance: Enhances system stability and efficiency.
• Rugged Construction: Ideal for demanding industrial environments.

Technical Specifications

• Power Supply: 24/48 VDC
• Power Consumption: 25W / 35VA
• Frequency Range: 50Hz, 60Hz, 16 2/3Hz
• Operating Temperature: -25°C to +70°C
• Storage Temperature: -40°C to +85°C
• Protection: IP54 (front), IP50 (rear)
• Communication: RS232, Modbus, Profibus
• Standards: IEC 60255-5, IEC 61000-4-2, IEC 61000-4-6, CE Marked
