ABB PM864K01 3BSE018150R1 processor unit kit
Manufacturer: ABB
Product Number: PM864K01 (3BSE018150R1)
Category: Processor Unit Kit
System Compatibility: ABB AC 800M and Advant 800xA distributed control platforms
Application: Delivers robust control capability for industrial settings including CPU board, backup power, and baseplate
Product Description
The ABB PM864K01 (3BSE018150R1) is a complete processor unit kit designed for the AC 800M and Advant 800xA distributed control platforms. It delivers robust control capability in industrial settings, with CPU board, backup power, baseplate, and necessary terminator modules all packaged for seamless installation and integration.
Main Features
-
Packaged as a full kit including CPU module (PM864), TP830 baseplate, CEX-bus, ModuleBus, and RCU-Link terminators, memory backup battery, and power plug.
-
Powered by a sturdy 48 MHz processor with 16 MB of memory—sufficient for moderate to complex control tasks.
-
Provides dual Ethernet and serial connectivity: two RJ-45 ports (CN1, CN2) and two RS-232C ports (COM3 for modem control, COM4 isolated for configuration tool).
-
Supports CPU redundancy to ensure high availability in control-critical systems.
-
Compact and rugged design featuring DIN-rail mount (TP830), IP20 protection, and proven modularity for expansion and maintenance.
-
Not RoHS-compliant; suitable as a spare for legacy systems prior to mid-2017, replaced by PM864AK01 for new installs.
Technical Specifications
Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 230 × 115 × 75 mm (approx. 9.06 × 4.53 × 2.95 in) |
| Weight | 1.1 kg (approx.) |
General Information
| Item | Specification |
|---|---|
| Manufacturer | ABB |
| Model Number | PM864K01 / 3BSE018150R1 |
| Product Type | Processor Unit Kit for AC 800M / Advant 800xA systems |
| Mounting | DIN-rail via TP830 baseplate; IP20 rated |
| Certifications | Legacy product; not RoHS-compliant; for repair/upgrades |
| Replacement Model | PM864AK01 recommended for new installations |
Processor & Memory
| Item | Specification |
|---|---|
| Processor | 48 MHz CPU (single processor) |
| Memory | 16 MB RAM; CompactFlash storage for firmware and data |
Connectivity & Redundancy
| Interface | Details |
|---|---|
| Ethernet | 2× RJ-45 ports (CN1, CN2) for network communication |
| Serial Ports | COM3: RS-232C with modem control; COM4: isolated RS-232C for configuration tool |
| Redundancy | Supports CPU, bus, and I/O redundancy for fail-over capability |
Included Accessories
| Component | Description |
|---|---|
| TP830 Baseplate | Mounting platform, width = 115 mm |
| TB850, TB807, TB852 | Terminators for CEX-bus, ModuleBus, RCU-Link |
| Memory Backup Battery | Ensures RAM retention during power loss |
| Power Plug | Four-position connector for power supply |
Industry Applications
The ABB PM864K01 is suited for industrial environments such as:
-
Process automation in oil & gas, petrochemical, and power generation facilities.
-
Manufacturing systems requiring modular, reliable CPU modules.
-
Water treatment, environmental monitoring, and infrastructure automation.
-
Legacy system maintenance and upgrades where RoHS compliance is not essential.
