Wago 750-409 4-channel Digital Input
Brand: Wago
Model Number:750-409
Type:4-channel Digital Input
Product Origin: Germany
Payment: T/T, Western Union, Credit Card
Dimensions: 87 x 24 x 23 mm
Weight: 40 g
Certificate: CE
Warranty: 1 years
Product Description
Since its inception in 1979, WAGO Corporation has fulfilled the needs of US industry by providing fast, safe and reliable connectivity solutions and value-added services that reflect the inherent values of a wide range of customers.
Technical data
| Number of digital inputs | 4 |
| Total number of channels (module) | 4 |
| Signal type | Digital |
| Signal type (voltage) | 24 VDC |
| Sensor supply | DC 24 V |
| Sensor connection | 2 x (2-wire, 3-wire); A suitable field side connection module (e.g., 750-614) must also be used to connect other sensors. |
| Input characteristic | low-side switching |
| Input filter (digital) | 0.2ms |
| Input current per channel for signal (0) typ. | 7mA |
| Voltage range for signal (0) | (UV – 5 V) … UV DC |
| Voltage range for signal (1) | −3 VDC … (UV – 15 V) |
| Input data width (internal) max. | 4Bit |
| Supply voltage (system) | 5 VDC; via data contacts |
| Current consumption (5 V system supply) | 5mA |
| Supply voltage (field) | 24 VDC (-15 … +20 %); via power jumper contacts (power supply via blade contact; transmission (supply voltage field side only) via spring contact) |
| Isolation | 500 V system/field |
| Indicators | LED (A-D) green: Status DI 1 … DI 4 |
| Number of incoming power jumper contacts | 2 |
| Number of outgoing power jumper contacts | 2 |
| Current carrying capacity (power jumper contacts) | 10A |
