WAGO 750-466 Product Introduction

WAGO 750-466 module is a multifunctional industrial interface module designed to connect sensors and actuators to automation systems.It can provide reliable signal transmission,data processing and control functions in complex industrial environments to ensure efficient and safe operation of the system.

Technical Features

Analog Input:The module has analog input function,which can receive analog signals from sensors and other devices and convert these signals into digital signals for control system processing.It supports 4…20mA single-ended signal input and is suitable for a variety of industrial automation application scenarios.

Remote I/O Configuration:WAGO 750-466 module supports remote I/O(input/output)configuration,which means that the signals of sensors and actuators can be transmitted to the central control room through a bus cable,thereby reducing the complexity and cost of wiring.

Signal Isolation and Protection:The module provides signal isolation function to prevent ground loops and electromagnetic interference,ensuring the stability and reliability of the signal.At the same time,it also has an overvoltage protection function,which can protect the system from damage caused by voltage spikes.

Modular design:The WAGO 750-466 module adopts a modular design,allowing the system to be easily expanded.New modules can be added at any time without affecting the structure of the existing system,which provides convenience for system upgrades and maintenance.

Rugged and durable:The module is designed with a sturdy shell that can withstand harsh conditions such as high temperature,high humidity,vibration and corrosive gases,ensuring long-term reliable operation.

Application areas

The WAGO 750-466 module is widely used in industrial automation systems,especially in situations where high precision and reliability are required.For example,in thermal power generation systems,it can be used as an interface between sensors and actuators and control systems to achieve signal conversion and transmission.At the same time,it can also be used for functions such as remote monitoring,data acquisition and processing,and linkage control between equipment to improve production efficiency and product quality.

Technical parameters

The following are some key technical parameters

Number of analog inputs:2 channels

Signal type:current(4…20mA)

Resolution:12 bits

Conversion time:typical value≤2ms

System power supply voltage:DC 5V

Current consumption(system power supply):75mA

Field power supply voltage:DC 24V(-25%…30%)

Isolation voltage:500V(system/power supply)
