GE Fanuc A02B-0120-B513 CNC Control System

The GE Fanuc A02B-0120-B513 is a CNC control system designed to provide accurate and reliable control for Series 16/18/21 Model A/B/C CNC machines. It supports up to 6-axis control, making it ideal for complex machining operations in industries like metalworking and fabrication. This system is commonly used in punch presses from manufacturers such as Amada, LVD, and Strippett.

Technical Specifications

• Product Type: CNC Control System
• Manufacturer: GE Fanuc (now part of FANUC)
• Series Compatibility: Series 16/18/21 Model A/B/C
• Part Number: A02B-0120-B513
• Function: Provides precise control for CNC machinery to enhance machining accuracy.
• Key Components:
  • Main CPU
  • Power supply unit
  • Option boards
  • Separate I/O card
  • Surface-Mounted Devices (SMDs)
• Axis Control: Supports up to 6-axis control, enabling multi-axis machining.
• Typical Applications: Used in punch presses (e.g., Amada, LVD, Strippett).
• Dimensions: 13.5 in x 7.0 in x 15.5 in (34.3 cm x 17.8 cm x 39.4 cm)
• Weight: 8 lbs 0.0 oz (3.6 kg)
