Functional Overview

Handles 32 independent channels.

Provides 24VDC high-side switching for actuators, valves, and more.

Key Features

• Powerful: Each channel delivers up to 3A current, ideal for demanding applications.
• Flexible: Integrates seamlessly with DeltaV systems for comprehensive control.
• Rugged: Operates reliably in harsh environments (-40°C to +70°C).
• Technical Specifications:

Power

• Local Bus Power: 12 VDC at 150 mA
• Bussed Field Power: 24 VDC at 3.2 A/card
• Field Circuit: 24 VDC at 100 mA/channel

Environmental

• Operating temperature: -40°C to +70°C
• Shock resistance: 10g

Please be aware that this information serves as a reference, and it is crucial to adhere to the specific instructions and guidelines outlined in the official product documentation to ensure safe and proper usage.
