The Emerson 8121-DI-DC-05 is a reliable and versatile digital input module designed for industrial automation applications. It interfaces with PAC8000 systems, providing connectivity for 16 digital input channels.

Features

• 16-Channel Digital Input: Connects to a wide range of sensors and switches.
• 24V DC Operation: Seamless integration with existing industrial power systems.
• Selectable Input Speed (2-512 ms): Optimizes performance for various signal types.
• Pulse Counting Option (Optional): Enables monitoring of repetitive digital events.

Technical Specifications

• Input Count: 16 channels
• Input Type: Digital
• Voltage: 24V DC (supply and on/off)
• Current Consumption: 50mA (system), 190mA (field)
• Input Speed: Selectable from 2ms to 512ms

Benefits

• Expands system capabilities: Integrates additional digital devices into your PAC8000 system.
• Improves operational efficiency: Provides real-time data for process control and monitoring.
• Enhances system reliability: Robust design ensures smooth operation in industrial environments.
