The Eaton 51154724-300 NE-FWMB01 is a specialized Modbus TCP firewall designed for industrial networks.

Key Features

• Modbus TCP Protection:
  • Provides robust security for Modbus TCP communications
  • Integrates seamlessly into existing industrial networks
• Two Ethernet Ports:
  • IEEE 802.3 BASE-T ports
  • Supports 10/100 Mbps speeds
  • Offers auto-sensing or manual configuration
• Power Supply:
  • Operates on 24 VDC
  • Consumes 0.15 A and 3.6 W
• Operating Temperature:
  • Wide range from -40°C to 70°C
• Storage Temperature:
  • Ranges from -40°C to 85°C
• Humidity:
  • Functional in 5% to 95% non-condensing environments
• Dimensions:
  • Compact size: 22.5 mm x 100 mm x 113.5 mm
• Weight:
  • 220 g
• Security Features:
  • Built-in firewall
  • Intrusion detection system for enhanced protection
• Installation:
  • Easy Plug-n-Protect technology
  • No preconfiguration or network disruption required
• Environmental Design:
  • Rugged construction
  • Suitable for harsh industrial conditions
• Diagnostics:
  • LEDs indicate power, mode, fault, save/load, reset, link status, and signal contact
