The Ovation 1C31113G04 Analog Input Module is a high-performance component designed specifically for the Ovation distributed control system (DCS). It serves as a critical interface for capturing and processing analog signals from field instruments, enabling precise monitoring and control in industrial automation environments. The module supports multiple channels of analog input, converting real-world electrical signals into digital data that the control system can use for analysis and decision-making.

This module is engineered for reliability, accuracy, and compatibility with a wide range of sensors and transducers. Its robust design ensures stable operation even in demanding environments such as power generation plants, petrochemical facilities, and other process industries.

Product Specifications

Applications

• Power Generation Plants: For continuous monitoring of temperature, pressure, flow, and other vital parameters.

• Oil & Gas Industry: Used in refining and processing units for accurate control of analog signals.

• Chemical Processing: To track critical variables for safe and efficient chemical reactions.

• Water & Wastewater Treatment: For precise input data from various sensors in water quality and flow measurement.

• Manufacturing Automation: Ensures reliable analog data input for controlling production lines and machinery.

• HVAC Systems: Integrated for monitoring environmental conditions to optimize system performance.

Advantages

• High Accuracy and Reliability: Ensures precise measurement essential for critical industrial processes.

• Robust Design: Built to withstand harsh industrial environments including temperature extremes and electrical noise.

• Wide Compatibility: Supports various signal types and interfaces seamlessly with the Ovation DCS.

• Easy Installation and Maintenance: Compact design with plug-and-play capability reduces downtime.

• Isolation and Protection: Galvanic isolation protects the system and enhances signal integrity.

• Flexible Configuration: Multiple channels allow customization for specific application needs.

• Long Service Life: Manufactured to rigorous standards ensuring dependable operation over years.

• Enhanced Safety: Reduces risk of erroneous data through stable signal processing.

Frequently Asked Questions (FAQ)

1. What types of signals does the 1C31113G04 module support?

   It supports common analog signals such as 4-20mA current loops and 0-10V voltage signals.

2. How many input channels does this module have?

   Typically, it provides 8 or 16 input channels, depending on the specific configuration.

3. Is the module compatible with all Ovation control systems?

   Yes, it is designed to fully integrate with the Ovation distributed control system.

4. What is the operating temperature range?

   The module operates safely between -20°C and +70°C.

5. Does the module provide electrical isolation?

   Yes, it features galvanic isolation between input channels and the backplane.

6. How precise are the measurements?

   The module offers an accuracy of ±0.1% of full scale, suitable for most industrial needs.

7. What are the physical dimensions of the module?

   It measures 45 x 120 x 200 mm.

8. What power supply voltage does the module require?

   It requires a 24 V DC power supply, which is standard for Ovation modules.

9. Can this module be used in hazardous environments?

   It is designed for industrial use but should be installed in accordance with local safety and hazardous area standards.

10. How easy is it to replace or upgrade the module?

    The module supports plug-and-play installation, making replacement and upgrades straightforward.
