The Ovation 1C31194G01 electronic module operates by receiving a signal from a control system, interpreting this signal, and converting it into a precise air pressure output. This air pressure is then supplied to the valve actuator, which adjusts the valve position accordingly. The module monitors the valve’s actual position and provides feedback to the control system, ensuring accurate and reliable valve control within industrial processes.

Here’s a breakdown of how it works and its key features:

1. Signal Reception and Interpretation: The module receives a signal from the control system, which likely contains instructions regarding the desired valve position or action.
2. Conversion to Air Pressure: It interprets this signal and converts it into a precise air pressure output. This conversion process likely involves internal circuitry and components designed to accurately regulate the air pressure.
3. Supplying Air Pressure to Actuator: The generated air pressure is then supplied to the valve actuator. The actuator is responsible for physically adjusting the valve’s position based on the pressure it receives.
4. Monitoring Valve Position: While the valve is in operation, the module continuously monitors the valve’s actual position. This monitoring ensures that the valve is responding correctly to the control signals and that the process is operating as intended.
5. Feedback to Control System: The module provides feedback to the control system regarding the valve’s actual position. This feedback loop allows the control system to make any necessary adjustments or corrections to maintain precise control over the process.

Key Features:

• Accurate Valve Control: The module delivers high-precision valve positioning, which is essential for reliable process control within industrial settings.
• Reliable Performance: Designed for harsh industrial environments, the module ensures consistent operation even in challenging conditions.
• Easy Integration: It seamlessly integrates with Emerson’s Ovation control system, facilitating smooth data exchange and interoperability within the automation ecosystem.
• Legacy Compatibility: The module is compatible with older Ovation systems up to version 3.4, allowing for wider applicability and compatibility with existing infrastructure.

Technical Specifications:

• Valve Type: Pneumatic
• Supply Voltage: 400VAC/540VDC
• Output Current: 30 Amp
• Enclosure Type: IP20/IP00 (NEMA UL Type Open)

These technical specifications provide information about the module’s electrical requirements and environmental protection ratings, ensuring suitability for industrial use.
