Allen‑Bradley 1756-TBCH Detailed Information

Allen‑Bradley 1756-TBCH is a product of Allen-Bradley(AB,Allen-Bradley)brand.The following is a detailed introduction to Allen‑Bradley 1756-TBCH.

Product Overview

Brand:Allen-Bradley(AB)

Model:1756-TBCH

Category:ControlLogix Removable Terminal Block(RTB)Assembly

Technical Specifications and Functions

Purpose

This assembly is used as a modular terminal block for 1756 I/O modules,providing modular and flexible terminal blocks for input and output devices.

It is an I/O module accessory and must be ordered separately.

Structure

36-pin cage clamp removable terminal block with standard housing.

The wiring arm depth is 2.5mm².

Installation

Insert into the front of the I/O module and hidden by the module door cover.

Suitable for clean and dry industrial environments of 0~60℃.

Application

Interconnecting 1756 I/O modules and industrial plant wiring provides flexibility.

Supports most 1756 ControlLogix modules.

Allows wires to be terminated without the need for an actual module,and can be terminated with an RTB alone.

Saves time during troubleshooting and maintenance,especially during module replacement.When replacing a module,the entire RTB is uninstalled from the main module and reinstalled on the replacement module without rewiring.

Wire connection

Use wires with a size of 0.33 to 2.1 square mm(22 to 14 AWG)solid or stranded copper wire for single-wire connection.

Or use 0.33 to 1.3 square mm(22 to 16 AWG)solid or stranded copper wire for double-wire connection.

Do not terminate more than two wires on the same terminal.

Application field

Allen‑Bradley 1756-TBCH is widely used in various industrial automation and control systems,including but not limited to manufacturing,process control,mechanical equipment and other fields.Its high performance,flexibility and reliability make it an advanced solution in the field of automation control.

Product features

Modular design:easy to install,maintain and upgrade,reducing the overall cost of the system.

Flexible configuration:Flexible I/O configuration and function expansion can be performed according to application requirements.

Multiple communication interfaces:Supports multiple communication interfaces and network protocols,such as Ethernet/IP,ControlNet,DeviceNet,etc.,providing seamless integration with other devices and systems.

High-performance processor:Ensures real-time responsiveness and processing capabilities of the system.

Security:Supports integrated security functions,complies with safety standards,and provides powerful fault diagnosis and safety monitoring functions.
