Schneider 140CHS11000 Product Overview

The 140CHS11000 module is an important part of Schneider’s Modicon Quantum automation control platform and is widely used in industrial automation control systems,such as DCS system modules.It supports Ethernet protocol and can be directly connected to Ethernet to achieve fast data transmission and remote monitoring.

Technical Specifications and Functions

Communication Protocol

Supports Modbus TCP/IP protocol and EtherNet/IP protocol,which is convenient for communication with various network devices.

Environmental Adaptability

The P67-level module is suitable for harsh environments such as high humidity,high temperature or water and oil spray.

It can be directly installed on the device without additional housing protection.

Display and Web Server

Built-in display,convenient for users to view the status and parameters of the module.

Integrated Web server,users can remotely access and configure the module through a browser.

Memory and Storage

1024kB internal RAM,expandable to 7168kB program with PCMCIA card.

8MB file storage expandable with PCMCIA card.

Switch Functionality

Key switch memory port open/close functionality.

Application Structure

Supports 1 cyclic/periodic master task,1 periodic fast task,128 I/O interrupt tasks,128 interrupt tasks,and 32 timer interrupt tasks.

Number of Instructions

10.28 Kinst/ms(if 100%Boolean)or 10.07 Kinst/ms(if 65%Boolean and 35%numeric).

Electrical Connections

1 RJ45 connector for Ethernet.

1 RJ45 connector for Modbus bus.

1 SUB-D 9 female connector for Modbus Plus network.

Indicators

1 green LED for Ethernet activity(COM).

1 red LED to indicate Ethernet conflict.

Application fields

140CHS11000 module is widely used in many fields such as mechanical control,manufacturing,infrastructure,process control,pharmaceutical,food and packaging industries.Its powerful communication capability and environmental adaptability make it an important part of industrial automation control system.
