Allen‑Bradley 1305-BA06A Product Introduction

Allen‑Bradley 1305-BA06A is a frequency converter product.The following is a detailed introduction to it.

Product Features

Communication rate:supports the predetermined communication rate in the standard specification,and supports manual setting of all standard rates or rate adaptation(all electrical interface rates are consistent)by the DIP switch.

Status indication:equipped with 6 dual-color LED status indicators and power failure relay output alarm function.

Electrical interface protection:with 4000V lightning protection,1.5A overcurrent,600W surge protection functions,meets industrial-grade design standards,and passed EMC test certification.

Power supply design:adopts DC9-36V wide redundant dual power supply,with DC1500V power supply isolation and reverse connection protection functions.

Protection level:IP30 protection level,adopts wavy aluminum reinforced casing,supports standard industrial 35mm rail installation.

Performance indicators

Data electrical interface:9-pin Sub_D jack connector,the pin definition conforms to the Profibus DP protocol specification,and supports the Profibus DP bus standard.

Communication rate range:supports multiple communication rates from 9.6kBit/s to 12MBit/s.

Lightning protection and overcurrent protection:has 4000V lightning protection and 1.5A overcurrent protection.

Power supply and protection:Dual power supply redundant input,DC(9-36)V,typical DC24V,power consumption less than 4W,with DC1500V voltage isolation and reverse connection protection,industrial terminal interface.Relay alarm output is link failure and power failure alarm output,contact capacity is DC48V/1A,industrial terminal interface.
