ABB ACS580-01-363A-4.1 Product Overview

ABB ACS580-01-363A-4.1 is a high-performance variable frequency drive (VFD) designed to control a broad range of variable and constant torque applications. It’s part of the ABB ACS580 series, known for its reliability, efficiency, and advanced features.

Key Parameters and Specifications

• Model Number ACS580-01-363A-4.1
• Manufacturer ABB
• Type Variable Frequency Drive (VFD)
• Power Rating 200 kW (268 HP)
• Voltage 380-480 V (3-phase AC)
• Current 363 A
• Frequency 0-60 Hz
• IP Rating IP21 (protected against solid objects larger than 50 mm and dripping water)
• EMC Class C2
• Cooling Forced air cooling

Dimensions and Weight

• Dimensions Approximately 800 x 500 x 300 mm (31.5 x 19.7 x 11.8 inches)
• Weight Approximately 50 kg (110 lbs)

Series and Characteristics

• Series ACS580
• Characteristics
  • Advanced vector control for precise torque and speed control
  • Energy-efficient operation
  • Integrated safety features
  • Wide range of communication options (Ethernet, CANopen, Modbus, etc.)
  • Customizable user interface
  • Robust construction for harsh environments

Role and Applications

The ABB ACS580-01-363A-4.1 VFD is primarily used to control the speed and torque of electric motors in various industrial applications. Some common applications include

• Pumps and fans Controlling the flow rate of fluids and gases.
• Conveyors Adjusting the speed of conveyor belts.
• Machine tools Precisely controlling the movement of machine tools.
• Textile machinery Controlling the speed of spinning and weaving machines.
• HVAC systems Regulating heating, ventilation, and air conditioning systems.
• Material handling Controlling the movement of materials in industrial processes.

List of Points

• Model Number: ACS580-01-363A-4.1
• Manufacturer: ABB
• Type: Variable Frequency Drive (VFD)
• Power Rating: 200 kW (268 HP)
• Voltage: 380-480 V (3-phase AC)
• Current: 363 A
• Frequency: 0-60 Hz
• IP Rating: IP21
• EMC Class: C2
• Cooling: Forced air cooling
• Dimensions: Approximately 800 x 500 x 300 mm
• Weight: Approximately 50 kg
• Series: ACS580
• Characteristics: Advanced vector control, energy-efficient, safety features, communication options, customizable interface, robust construction
• Role: Controls speed and torque of electric motors
• Applications: Pumps, fans, conveyors, machine tools, HVAC, material handling

Note:These are general specifications. For exact details, please refer to the official ABB documentation or consult with an ABB representative.
