PROSOFT MVI69-PDPMV1 Product Introduction

The PROSOFT MVI69-PDPMV1 communication module is a high-performance communication module designed for industrial automation.It was developed by Prosoft Technology and is part of its inRAx sub-brand.The module is widely used in industrial automation fields that require efficient and reliable communication solutions,especially when using Rockwell Automation®CompactLogix®and MicroLogix®series PLCs.

Main features

Multiple communication protocol support

Supports multiple communication protocols such as Ethernet/IP,Modbus TCP/IP and DeviceNet,making it easy to communicate with different devices and controllers.

Specially supports PROFIBUS DP V1 master protocol,complies with IEC 61158 standard,and can be seamlessly integrated with PROFIBUS slave devices.

PLC compatibility

Highly compatible with Rockwell Automation’s ControlLogix®and CompactLogix®series PLCs,including CompactLogix L20,L23,L30,L31,L32,L35,L43 and L45 models.

Most MicroLogix 1500 LRP controllers are also supported,providing a wide range of applicability.

Powerful data exchange capabilities

Equipped with data mapping functions,it can quickly map and convert data between different communication protocols to ensure the correct transmission and interpretation of data.

Through ladder logic,efficient data transmission is achieved between module memory and processor controller tags.

Easy to configure and manage

Comes with ProSoft Configuration Builder software for configuring PROFIBUS networks and downloading configurations to modules through the serial port of a PC.

Supports project-specific GSD file import libraries for fast configuration and debugging.

Real-time monitoring and diagnostics

Supports real-time monitoring and diagnostic functions to help users quickly detect and solve communication problems and improve system availability.

Provides master station status LED indicators to display status such as operation,network communication,master token retention,and network configuration.

High reliability and scalability

Adopts optically isolated RS-485 PROFIBUS interface with onboard DC-DC converter to improve anti-interference ability.

Supports connecting up to 125 slave devices through repeaters and processes up to 1536 cyclic bytes of input and output data.

Supports stacking and expansion of modules,making it easy to connect more devices and communication channels to meet growing needs.

Industrial-grade design

Complies with multiple international safety standards,including ATEX directive,CE,CB safety,Lloyd’s Register,C/UL Class 1 and Class 2 certifications.

Adapts to a wide range of industrial environments,with an operating temperature range of 0 to 60 degrees Celsius,a storage temperature range of-40 to 85 degrees Celsius,and a relative humidity of 5%to 95%(non-condensing).

Application areas

The PROSOFT MVI69-PDPMV1 communication module is suitable for various industrial automation occasions,especially where efficient and reliable communication solutions are required.It can be used to connect different types of devices and controllers to achieve data collection,transmission and control,and improve production efficiency and automation level.
